| Size: |
4.72 in. sq. x 1.26 in. thk.
(120 mm sq. x 32 mm thk.) |
| AirFlow: |
60.0 - 120.1 CFM |
| Acoustical Noise: |
33.5 - 50.5 dB (A) |
| Materials : |
Frame - Black PBT (UL 94V-0)
Bearings - Ball
Impeller - Black PBT (UL 94V-0) |
| Weight : |
8.82 oz. (250g) |
| Termination : |
Lead Wires (UL 1007, AWG24 or equivalent) |
| Operational Temperature : |
-10°C to +70°C |
| Insulation Resistance : |
10 Megohms min. @ 500 VDC |
| Dielectric Strength : |
500 VAC for 1 min. |
| Insulation : |
Class A |
| Safety : |
Impedance & Polarity Protected |
| Safety Approvals : |
UL, CSA, & CE |
| Operating Voltage : |
12 VDC (6 to 13.8)
24 VDC (14 to 27.6)
48 VDC (28 to 56) |
